Overview :
This product is the accessory product for the LED lighting controlling, used to control a variety of LED lighting as the light source brightness, such as: LED soft light strip, LED rigid light strip, ,Dim Led lamp,LED modules and so on. With manual adjustment knob to adjust the lighting brightness, wiring convenient, simple and intuitive.
Specifications:
Voltage:DC12V-24V
Current:8A *1CH
Power Dissipation:<0.5W
Size: 95*60*5.5 mm
Work Temperature:-20~+60degree
Power output: 12V-96 W,24V-192W
Application:
The input voltage of this controller should be follow the specifications, other high voltage would most probably destroy it
The 4wires coming out of the controller can’t be incorrectly interconnected or short circuit could occur
Connect the wires of the controller and LED fittings as per the instruction
Don’t peel off the label on the controller in case any indication information will be missed
The standard warranty is one yeas Our company won’t be responsible for any damage of the Controller due to any wrong operation.
Package included:
1 x Led Dimmer Controller
